(EyeRIS A10 EP86-S1)
| Specification | Details |
|---|---|
| Model | EP86-S1 |
| Display Size | 86″ (218 cm) |
| Display Type | 10-bit IPS, 4K UHD, Zero-bonding |
| Resolution | 3840 × 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Brightness | 500 nits |
| Contrast Ratio | 100,000:1 (dynamic) |
| Touch Technology | Optical-edge PixelTouch |
| Touch Support | 40-point (Windows), 20-point (Android) |
| Touch Accuracy | ±0.3 mm |
| Operating System | Android 14 (AI-powered) |
| Processor | Octa-core ARM Cortex-A55 |
| GPU | Mali-G52 MP2 |
| RAM | 8 GB DDR4 |
| Storage | 128 GB eMMC + Unlimited Cloud |
| Audio Output | 2 × 20W stereo with passive bass |
| Wireless Casting | AirPlay, Miracast, Chromecast |
| Connectivity | Wi-Fi, LAN, Bluetooth, HDMI, USB |
| Ports / I/O | USB-C, USB 2.0/3.0, HDMI IN ×2, LAN, Audio, RS232 |
| Camera Support | USB Camera Compatible |
| Included Accessories | Remote, Stylus, Wall Mount, HDMI & USB cables |
| Mounting Type | VESA 600 × 500 mm |
| Dimensions | 1950 × 110 × 1180 mm |
| Weight | Net: 61 kg / Gross: 70 kg |
| Power Consumption | ≤400 W (standby <0.5 W) |
| Power Supply | AC 100–240V, 50/60Hz |
| Country of Origin | India |
About This Item
- MASSIVE 86″ 4K UHD 10-BIT IPS ZERO-BONDING INTERACTIVE DISPLAY – Huge 10-bit IPS panel with zero-bonding anti-glare coating, 500 nits brightness (highest in range), and 100,000:1 dynamic contrast for stunning large-format smart classroom and boardroom visuals.
- ANDROID 14 AI-POWERED OS | 8 GB DDR4 RAM | 128 GB eMMC + UNLIMITED CLOUD – AI-powered Android 14 with unlimited cloud storage on an Octa-core Cortex-A55 powers seamless performance across the largest, most demanding group learning and enterprise environments.
- OPTICAL-EDGE PIXELTOUCH — ±0.3MM INDUSTRY-LEADING PRECISION – Cybernetyx’s proprietary PixelTouch delivers ±0.3mm touch accuracy across the entire 86-inch interactive surface for ultra-fine writing, drawing, and annotation at any point.
- 40-POINT (WINDOWS) / 20-POINT (ANDROID) MULTI-TOUCH – Full multi-user simultaneous touch support with stylus and finger across Windows and Android modes for immersive, large-group classroom collaboration.
- DUAL 20W SPEAKERS WITH PASSIVE BASS – 40W bass-enhanced stereo audio output fills even the largest classrooms and auditoriums with rich, clear sound for lectures and instructional content.
- FULL I/O + WIRELESS CASTING | MADE IN INDIA – USB-C, USB 2.0/3.0, HDMI IN×2, LAN, RS232, Audio; AirPlay, Miracast, Chromecast; VESA 600×500mm; proudly Made in India with manufacturer warranty.
Frequently Asked Questions (FAQs)
1. What display quality does this interactive panel offer?
The panel features a massive 86-inch 4K UHD 10-bit IPS display with zero-bonding anti-glare technology, 500 nits brightness, and exceptional color accuracy for immersive viewing.
2. What operating system and hardware power the panel?
It runs on Android 14 with an Octa-core Cortex-A55 processor, 8GB DDR4 RAM, and 128GB eMMC storage, ensuring smooth performance for demanding applications.
3. What is PixelTouch technology?
PixelTouch is Cybernetyx’s proprietary touch technology that delivers ±0.3mm precision, enabling highly accurate writing, drawing, and annotation.
4. How many touch points does the panel support?
The display supports 40-point multi-touch on Windows and 20-point multi-touch on Android, allowing multiple users to collaborate simultaneously.
5. Does the panel include built-in audio?
Yes, it comes with dual 20W speakers with passive bass radiators, delivering rich and powerful sound for large classrooms and meeting spaces.
6. What connectivity options are available?
The panel supports USB-C, USB 2.0/3.0, HDMI, LAN, RS232, Audio ports, and wireless casting through AirPlay, Miracast, and Chromecast.
7. Is this interactive panel suitable for large-scale learning and business environments?
Yes, it is ideal for universities, large schools, coaching institutes, training centers, auditoriums, boardrooms, and conference halls.
8. Can this interactive panel support institutions across Bihar’s major divisions?
The panel is well-suited for digital classrooms, government training centers, educational institutions, and corporate offices across Patna, Tirhut, Magadh, Munger, Bhagalpur, Purnea, Kosi, Saran, and Darbhanga Divisions, where large groups can benefit from its expansive screen, precise touch technology, and collaborative features.
Reviews
There are no reviews yet.
